| RTK Tablet |
| PERFORMANCE | |
| Signal Received | |
| GPS | L1/L2/L5/L-Band |
| GLONASS | L1/L2/L3 |
| BDS | B1/B2/B3 |
| GALILEO | E1/E5a/E5b/E6 |
| QZSS | L1/L2/L5/L6 |
| IRNSS | L5 |
| Nominal Impedance | 50Ω |
| Polarization | RHCP |
| Axial Ratio | ≤3dB |
| Gain At Zenith(90°) | |
| 1164-1130MHz | 5.5dBi(Maximum) |
| 1525-1615MHz | 5.5dBi(Maximum) |
| LNA Gain | 40dB±2dB |
| Noise Figure | ≤2dB |
| Output/Input VSWR | ≤2.0 |
| Operation Voltage | +3.3VDC to +12VCD |
| Operation Current | ≤45mA |
| Group Delay Ripple | ≤5ns |
| MECHANICAL | |
| Dimensions | ø154*64.2mm |
| Connector | TNC-K |
| Weight | 391G |
| Mounting | BSW5/8″ -11 Scrrew, 12-14mm |
| ENVIRONMENTAL | |
| Temperature | |
| Operating temperature | -40℃ to +85℃ |
| Storage temperature | -55℃ to +85℃ |
| Humiditiy | 95% non-condensing |
| Water/Dust Resistance | IP67 |
| Regulatory Compliance | NGS, FCC, CE, RoHS |
